Bosch GCL 2-15 User Manual

English | 19
Bosch Power Tools 1 609 92A 32T | (22.6.16)
Working with Automatic Levelling
If the measuring tool is outside of the self-levelling range, the
laser lines and/or points will flash quickly.
If during work with automatic levelling you switch to the
“working without automatic levelling” mode (On/Off switch 2
in position “”) the first combination of this mode’s indi-
cators is always activated.
Working without Automatic Levelling
The laser lines flash slowly in the “working without automatic
levelling” mode.
If during work without automatic levelling you switch to the
“working with automatic levelling” mode (On/Off switch 2 in
position “”) the first combination of this mode’s indi-
cators is always activated.
Sequence of actions
Horizontal
line
operation
Vertical line
operation
Point
operation
Indicator 3
for battery
capacity
Indicator 4 for
working without
automatic
levelling
Figure
On/Off switch 2 in position “”
 
 green B1
Cross-line operation
Press button for “laser line”
operating mode 6 once
 –  green C1
Press button for “laser line”
operating mode 6 twice
–   green D1
Press button for “laser line”
operating mode 6 three
times
– –  green E1
Press button for “laser line”
operating mode 6 four times
 
 green B1
Cross-line operation
Point operation can be activated or deactivated regardless of the line operation setting:
Press button for “laser
point” operating mode 5
once
 /–  /– –green
Press button for “laser
point” operating mode 5
twice
 /–  /–  green
Sequence of actions
Horizontal
line
operation
Vertical line
operation
Point
operation
Indicator 3
for battery
capacity
Indicator 4 for
working without
automatic
levelling
Figure
On/Off switch 2 in position “”
 
–greenredF1
Cross-line operation
Press button for “laser line”
operating mode 6 once
 – –greenred
Press button for “laser line”
operating mode 6 twice
–  –greenred
Press button for “laser line”
operating mode 6 three
times
 
–greenredF1
Cross-line operation
OBJ_BUCH-2637-002.book Page 19 Wednesday, June 22, 2016 4:13 PM

Bosch GCL 2-15 Specifications

General

Laser Diode	635 nm, < 1 mW
Laser Class	2
Working Range	15 m
Leveling Accuracy	± 0.3 mm/m
Self-Leveling Range	± 4°
Dust and Splash Protection	IP54
Power Supply	3 x 1.5 V LR6 (AA)
Tripod Thread	1/4"
Weight	0.49 kg
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +70°C
Levelling Time	4 s
Battery Life	Up to 8 hours
