Functional Description
To reduce the risk of injury user must read instruction manual for the
use of the power tool with this attachment.
SAVE THESE INSTRUCTIONS
1 Dust collector unit.
2 Button for drilling depth adjustment.
3 Small dust intake ring.
4 Guide with depth stop scale.
5 Dust box release tab.
6 Button for drill bit length adjustment.
7 Viewing window.
8 On/Off Switch pushbutton.
9 Battery charge level indicator
10 Mounting Cradle
11 Dust intake ring release tab.
12 Dust box*.
13 HEPA filter*.
14 Locking tab of the HEPA filter*.
15 Battery pack**.
16 Battery pack release button*
17 Large dust intake ring.
18 Extension
19 Retention latch
20 Retention catch
21 Auxiliary handle
22 Clamping collar
23 Index pins
* not shown
** available separately
Fig. 1
