English - 2
The numbering of the machine elements refers to
the illustration of the machine on the graphics
page.
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.
1 Gear selector
2 Torque setting ring
3 Keyless chuck
4 On/Off switch
5 Rotational direction switch
6 Battery*
7 Universal bit holder*
8 Battery unlocking button
9 Auxiliary handle*
10 Soft grip
11 Clamping band*
12 Screwdriver blade*
13 Screwdriver bit*
14 Allen key*
15 Locking screw
16 Cover lid
17 Brush holder
* Not all of the accessories illustrated or described are
included as standard delivery.
GSR 12 VE-2/GSR 14,4 VE-2/GSR 18 VE-2/
GSR 24 VE-2: The machine is intended for driv-
ing in and loosening screws as well as for drilling
in wood, metal, ceramic and plastic.
GSB 12 VE-2/GSB 14,4 VE-2/GSB 18 VE-2/
GSB 24 VE-2: The machine is intended for driv-
ing in and loosening screws, for drilling in wood,
metal, ceramic and plastic and for impact drilling
in brick, concrete and stone.
Read all instructions. Failure to
follow all instructions listed below
may result in electric shock, fire
and/or serious injury.
Additionally, the general safety instructions either
in the enclosed booklet or those added in the
centre of these operating instructions must be ob-
served.
SAVE THESE INSTRUCTIONS.
■ Secure the workpiece. A workpiece clamped
with clamping devices or in a vice is held more
securely than by hand.
■ Before any work on the machine (e. g.
maintenance, tool change, etc.) as well as
when transporting and storing, always set
the rotational direction switch to the centre
position. Unintentional actuating of the On/
Off switch may result in personal injury.
■ Do not open the battery yourself. There is
danger of a short circuit.
■ Protect the battery from heat and fire. There
is danger of explosion.
■ Hold the machine with a firm grip. High re-
action torque can briefly occur while driving in
and loosening screws.
GSB 12 VE-2/GSB 14,4 VE-2/
GSB 18 VE-2/GSB 24 VE-2:
■ Wear hearing protection when working
with impact drills. Exposure to noise can
cause hearing loss.
■ Use appropriate detectors to determine if
utility lines are hidden in the work area or
call the local utility company for assist-
ance.
Contact with electric lines can lead to fire and
electric shock. Damaging a gas line can lead
to explosion. Penetrating a water line causes
property damage.
■ Hold the machine only by the insulated
gripping surfaces, when performing an op-
eration where the cutting tool may run into
hidden wiring. Contact with a “live” wire will
make exposed metal parts of the tool “live” and
shock the operator.
Machine Elements
Intended Use
For Your Safety
2 609 932 156.book Seite 2 Dienstag, 29. März 2005 9:26 09
13 • 2 609 932 156 • TMS • 21.02.05
