ELETTRODOMESTICI
VIA CHECCHI 98
I 21013 GALLARATE
ITALY
Page 6 of 28
Tuesday, June 18, 2002
BOSCH 700 SERIES:
SERVICE INSTRUCTIONS FOR OVEN TESTING AND BASIC TROUBLESHOOTING
The tables below show the two different sets of options when entering the oven model selection menu for the double or single oven:
N° MOD DISPLAY DOUBLE OVEN MODELS
1 C 30 CONVECT 2 30” DOUBLE OVEN MULTIFUNCTION/MULTIFUNCTION
3 D 30 THERMAL 2 30” DOUBLE OVEN MULTIFUNCTION/THERMAL
5 G 27 CONVECT 2 27” DOUBLE OVEN MULTIFUNCTION/MULTIFUNCTION
7 H 27 THERMAL 2 27” DOUBLE OVEN MULTIFUNCTION/THERMAL
N° MOD DISPLAY SINGLE OVEN MODELS
0 A 30 CONVECT 1 30” SINGLE MULTIFUNCTION
2 B 30 THERMAL 1 30” SINGLE THERMAL
4 E 27 CONVECT 1 27” SINGLE MULTIFUNCTION
6 F 27 THERMAL 1 27” SINGLE THERMAL
KEEP THE [START] KEY PRESSED
DBL=>SGL transition: the Display Board resets itself. Wait for the clock on the display.
DBL=>DBL or SGL=>SGL transition: the control accepts the new selection, sounds a tone and updates the letter in the _0047 code
displayed. The Display Board doesn’t reset. Press [Cooking Mode] key again to quit the oven model selection menu and go back to
Manual Test.
