4 OPERATION
This section includes basic information about how the 800 Series wall
ovens operate.
4.1 Allowable Operating Range by Cooking Mode
Table 2 reflects the minimums and maximums by cooking mode for
each model in the 800 Series.
Cooking Mode
Models
Min
Max
Default
Bake
All
100°F
550°F
350°F
Broil (Low 450°F /
High 550°F)
450°F 550°F High
Roast
100°F
550°F
325°F
Warm
140°F
225°F
170°F
Sabbath
100°F
425°F
N/A
Self-Cleaning
2
hours
4 hours 3 hours
Proof Dough
HBL8442UC
HBL8451UC
HBL8461UC
HBN8451UC
HBL8642UC(u)
HBL8651UC(u)
HBL8661UC(u)
HBN8651UC
HBL8742UCC
HBL8752UCC
HBL87M52UCC
85°F 125°F 100°F
Convection Bake
HBL8442UC
HBL8451UC
HBL8461UC
HBN8451UC
100°F
550°F
325°F
Convection Broil
450°F
550°F
High
Convection Roast
100°F
550°F
325°F
Pizza
100°F
550°F
400°F
Cooking Mode
Models
Min
Max
Default
Multi-Rack
Convection
(Eur. Conv.)
HBL8642UC(u)
HBL8651UC (u)
HBL8661UC (u)
HBN8651UC(u)
HBL8752UCC
HBL87M52UCC
HBL8442uc
HBL8451UC
HBL8461UC
HBN8451UC
HBL8642UC(u)
HBL8651UC (u)
HBL8661UC (u)
HBN8651UC(u)
HBL8742UCC
HBL8752UCC
HBL87M52UCC
100°F 550°F 325°F
Fast Preheat N/A N/A
Not available
for Broil, Conv
Broil, Proof
Dough or
Warm
Probe
100°F
200°F
N/A
Convection
Conversion
N/A N/A
Auto Temp
Reduction by
25°F
(u) = upper oven only
4.2 Heating Elements
All ovens include an 8-pass 3800W broil element and a 4-pass
2400W bake element. Models with Euro-convection include a 2000W
ring element as well.
When the door is opened, all heating elements (and the convection
fan, if applicable) will be paused. When the door is closed, cycling will
continue.
Table 2 Allowable range by cooking mode
