The dishwasher drain hose may be connected to the drain plumbing using
an air gap in one of two ways:
Connect to the under sink dishwasher drain connection (25a).
Connect to a disposer dishwasher drain connection (25b).
NOTE: Place hose clamp around end of drain hose BEFORE connecting
to the plumbing.
The dishwasher drain hose may be connected to the drain plumbing using
a high loop in one of two ways:
Connect to the under sink dishwasher drain connection (25c).
Connect to a disposer dishwasher drain connection (25d).
