Use the clamp provided (C) to attach
the drain hose to the house plumbing as
shown.







26
Attaching the Toe Panel
If your dishwasher came with a slotted toe panel (F) follow these in-
structions; otherwise skip to 28 now.
Position the slotted toe panel (F) on the dishwasher. Allow it to rest on
WKHÀRRU
Attach using screws (G) as shown. Use only the supplied screws to avoid
GDPDJLQJWKHGLVKZDVKHU7KHWRHSDQHOVKRXOGEHÀXVKZLWKWKHÀRRU<RXU
installation is complete!
27
C
F
G
