26
If your dishwasher came with a non-slotted toe panel (H) and toe panel
brackets (J) follow these instructions:
Plug metal brackets (J) into openings on both sides of the base as shown.
Use screw (I) to mount metal brackets to the base as shown.
Tuck the pre-attached rubber DSURQ EHKLQG WKH ¿QJHUV RQ WKH PHWDO
brackets as shown.
28
29
I
J
