14 en | Technical data LB20 EVAC Cabinet Loudspeaker Models
2017.09 | V.02 | F.01U.345.361 Installation manual Bosch Security Systems B.V.
5.1 Dimensions
180.0 mm
[7.09 in]
255.0 mm
[10.04 in]
171.1 mm
[6.74 in]
150.1 mm
[5.91 in]
195.1 mm
[7.68 in]
Figure5.1: LB20-PC60EW-5 dimensions
5.2 Frequency response and impedance
Figure5.2: LB20-PC60EW-5 frequency response and impedance
