LB20 EVAC Cabinet Loudspeaker Models Table of contents | en 3
Bosch Security Systems B.V. Installation manual 2017.09 | V.02 | F.01U.345.361
Table of contents
1
Safety 4
1.1 Suspension 4
1.2 Notices 4
2
Introduction 5
2.1 System features 5
2.2 Product information 5
2.3 Packing list 6
3
Installation and wiring 7
3.1 Installing the speaker 7
3.2 U-Bracket installation options 8
3.3 Wiring 9
3.4 Transformer taps 10
3.5 Replacing the logo 11
4
Troubleshooting 12
5
Technical data 13
5.1 Dimensions 14
5.2 Frequency response and impedance 14
6
U-Bracket dimensions 15
