LC1 Modular Ceiling Loudspeaker Range Installation | en 13
Bosch Security Systems B.V. Product Information & Installation Manual F.01U.076.021 | V1.0 | 2012.04
Fig. 7
Optional
Fig. 8
Notice! Push until you hear a click.
Fig. 9 Fig. 10
Optional
Pilot tone indication board: LC1-PIB
Notice! Push until you hear a click.
Fig. 11
Optional
Line/Loudspeaker supervision boards:
LBB 4441/00, LBB 4442/00, LBB 4443/00
Fig. 12
1
2
Max.
Max.
50 mm
50 mm
(1.97 in)
(1.97 in)
2
1
