LC1 Modular Ceiling Loudspeaker Range Technical Data | en 19
Bosch Security Systems B.V. Product Information & Installation Manual F.01U.076.021 | V1.0 | 2012.04
3.2 Mechanical
LC1-WC06E8 LC1-WM06E8 LC1-UM06E8
Description Ceiling loudspeaker Ceiling loudspeaker Ceiling loudspeaker
Diameter 220 mm (8.67 in) 220 mm (8.67 in) 220 mm (8.67 in)
Maximum depth
(including LC1-MMSB)
125 mm (4.92 in) 125 mm (4.92 in) 125 mm (4.92 in)
Mounting cut-out 190 mm (7.48 in) 190 mm (7.48 in) 190 mm (7.48 in)
Color White (RAL 9010) White (RAL 9010) White (RAL 9010)
Material
(frame and front grille)
ABS Steel Steel
Weight 0.82 kg (1.80 lb) 1.18 kg (2.60 lb) 1.16 kg (2.56 lb)
LC1-UM12E8 LC1-UM24E8
Description Ceiling loudspeaker Ceiling loudspeaker
Diameter 220 mm (8.67 in) 220 mm (8.67 in)
Maximum depth
(including LC1-MMSB)
125 mm (4.92 in) 125 mm (4.92 in)
Mounting cut-out 190 mm (7.48 in) 190 mm (7.48 in)
Color White (RAL 9010) White (RAL 9010)
Material
(frame and front grille)
Steel Steel
Weight 1.30 kg (2.86 lb) 1.75 kg (3.86 lb)
LC1-MMSB LC1-CMR LC1-CBB
Description Mounting support bracket Ceiling mounting ring Back box
Dimensions 215 x 125 x 56 mm
(8.47 x 4.92 x 2.2 in)
215 x 70 mm
(8.47 x 2.75 in)
196 x 70 mm
(7.72 x 2.75 in)
Mounting cut-out 190 mm (7.48 in) 200 mm (7.88 in) -
Color Zinc plated White (RAL 9010) White (RAL 9010)
Material Steel ABS ABS
Weight 0.32 kg (0.70 lb) 0.21 kg (0.46 lb) 0.17 kg (0.38 lb)
LC1-MFD LC1-CSMB LC1-MSK
Description Metal fire-dome Surface mounting box Metal suspension kit
Dimensions 215 x 155 mm
(8.47 x 6.1 in)
220 x 128 mm
(8.67 x 5.04 in)
320 mm (12.59 in)
(chain length)
Mounting cut-out 190 mm (7.48 in) - -
Color Flame red (RAL 3000) White (RAL 9010) Zinc plated
Material Steel ABS Steel
Weight 1.00 kg (2.20 lb) 0.69 kg (1.52 lb) 0.17 kg (0.38 lb)
