Bosch LC1 - LC1-CSMB Housing Installation

12 en | Installation LC1 Modular Ceiling Loudspeaker Range
F.01U.076.021 | V1.0 | 2012.04 Product Information & Installation Manual Bosch Security Systems B.V.
2.3 LC1-MFD
Fig. 1 Fig. 2
Fig. 3 Fig. 4
Fig. 5 Fig. 6
190 mm190 mm
(7.48 in)(7.48 in)
