English–2
1 609 929 J06 • (05.07) T
Please refer to the article number on the nameplate of your unit since the
trade designation of individual units can vary.
The numbering of the product elements refers to the illustration of the unit
on the graphic page.
1 “Mode” button for measuring mode
2 On/Off switch with transport safety
3 Laser beam outlet
4 1/4" threaded hole (photo tripod attachment)
5 Battery compartment cover
6 Warning sign
7 Laser viewing glasses*
8 Protective bag
9 Tripod (commercially available)*
* Not all the accessories illustrated or described are included in standard
delivery.
The measuring instrument is intended for the determination and checking
of horizontal and vertical lines.
■ Protect the unit from moisture and direct sunrays.
■ Do not expose the unit to extreme temperatures and temperature var-
iations (e.g., do not leave in vehicles).
■ If the unit is not used for a long period, the batteries must be removed
(danger of self-discharge and corrosion).
■ Switch off the unit after use.
Product Specifications
Cross Line Laser PCL 1
Article number 3 603 K08 0..
Accuracy ±0.5 mm/m
Laser class 2M
Laser type 635 nm, <5 mW
Self-levelling range ±5°
Levelling time, typically 4 s
Operating temperature +5 °C ... +40 °C
Storage temperature –20 °C ... +70 °C
Batteries 4 x 1.5 V DC LR6 (AA)
Weight in accordance with
EPTA-Procedure 01/2003 0.5 kg
Product Elements
Intended Use
Protection of the Unit
pcl1_bu_1609929J06_t.fm Seite 2 Freitag, 29. Juli 2005 9:57 09
