Bosch PLR 50 - Display Elements; Technical Data

18 | English
2 609 140 621 | (18.7.11) Bosch Power Tools
14 Positioning pin
15 Latch of the positioning pin
16 Spirit level
17 Latch of battery lid
18 Battery lid
19 Laser beam outlet
20 Reception lens
21 Serial number
22 Laser viewing glasses*
23 Carrying strap
24 Laser target plate*
25 Protective pouch
* The accessories illustrated or described are not included as standard delivery.
Display Elements
a Variable measuring functions
Length measurement
Continuous measurement
Area measurement
Volume measurement
Indirect length measurement
b Battery low indicator
c Temperature warning
d Measured value/result
e Unit of measure
f Measurement reference level
g Laser switched on
h Individual measured value (for length measurement: result)
i Measured values stored
Technical Data
Digital Laser Rangefinder PLR 50
Article number
3 603 K16 300
Measuring range
0.05–50m
A)
Measuring accuracy (typically) ± 2.0 mm
B)
Lowest indication unit 1mm
Operating temperature
– 10 °C ... +50 °C
C)
Storage temperature – 20 °C ... +70 °C
Relative air humidity, max.
90 %
Laser class
2
Laser type
635 nm, <1 mW
Laser beam diameter (at 25 °C) and at 10 m dis-
tance, approx.
6mm
Batteries
Rechargeable batteries
4 x 1.5 V LR03 (AAA)
4 x 1.2 V HR03 (AAA)
Battery live, approximately
– Individual measurements
– Continuous measurement
30000
D)
5h
D)
Weight according to EPTA-Procedure 01/2003 0.18 kg
