66 en | *Amplifier, 600W 4-channel | PRA-AD604 PRAESENSA
2019.11 | V1.00 | Installation manual Bosch Security Systems B.V.
8.3 Functional diagram
Functional and connection diagram Internal device functions
DC to DC converter
Audio processing (DSP)
OMNEO network switch
Controller
Lifeline control interface
Lifeline supply input
Lifeline audio input
1-4 Amplifier channel
Spare channel
