Delivery Scope
Jigsaw.
“Cut Control”, splinter guard, application tools and other ac-
cessories shown or described are not part of the standard de-
livery scope.
A complete overview of accessories can be found in our ac-
cessories program.
Intended Use
The machine is intended for making separating cuts and cut-
outs in wood, plastic, metal, ceramic plates and rubber while
resting firmly on the workpiece. It is suitable for straight and
curved cuts with mitre angles to 45°. The saw blade recom-
mendations are to be observed.
Technical Data
The technical data of the machine are listed in the table on
page 63.
The values given are valid for a nominal voltage [U] of 230 V.
For different voltages and models for specific countries,
these values can vary.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 22.04.2013
Before any work on the machine
itself, pull the mains plug from the
socket outlet
Wear protective gloves
Additional information
Movement direction
Reaction direction
Next step of action
Prohibited action
Correct result
Extraction
Sawdust blower device
Switching On
Switching Off
On/Off switch lock-on
When sawing metal, apply coolant/
lubricant alongside the cutting line
Saw with moderate pressure in
order to achieve optimal and precise
cutting results
Article number (10-digit)
P
1
Rated power input
n
0
Stroke rate at no-load
Cutting depth, max.
Wood
Aluminium
Symbol Meaning
Metal
Particle board
Weight according to
EPTA-Procedure 01/2003
/II Symbol for protection class II
(completely insulated)
L
pA
Sound pressure level
L
wA
Sound power level
KUncertainty
a
h
Vibration total value
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
Symbol Meaning
