English | 11
Bosch Power Tools 1 609 92A 082 | (31.5.13)
Noise/Vibration Information
The measured values of the machine are listed in the table on
page 63.
Noise and vibrational values (vector sum of three directions)
determined according to EN 60745.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Mounting and Operation
Maintenance and Cleaning
For safe and proper working, always keep the machine
and the ventilation slots as well as the tool holder
clean.
Clean the saw blade holder regularly. For this, remove the saw
blade from the machine and lightly tap out the machine on a
level surface.
Check the guide roller regularly. If worn, it must be replaced
through an authorised Bosch after-sales service agent.
Lubricate the guide roller occasionally with a drop of oil (see
figure 14, page 70).
After-sales Service and Application
Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. Exploded views and information on spare parts can al-
so be found under:
www.bosch-pt.com
Bosch’s application service team will gladly answer questions
concerning our products and their accessories.
In all correspondence and spare parts order, please always in-
clude the 10-digit article number given on the type plate of
the machine.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: (0844) 7360109
Fax: (0844) 7360146
E-Mail: boschservicecentre@bosch.com
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: (01) 4666700
Fax: (01) 4666888
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: (01300) 307044
Fax: (01300) 307045
Inside New Zealand:
Phone: (0800) 543353
Fax: (0800) 428570
Outside AU and NZ:
Phone: +61 3 95415555
www.bosch.com.au
Action Figure Page
Inserting the Saw Blade 1 64
Removing the Saw Blade 2 64
Adapting the position of the guide
roller 3 64
Mounting the splinter guard 4 65
Mounting and use of “Cut Control” 5 65
Connecting the dust extraction 6 66
Adjusting the Cutting Angle 7 66 – 67
Switching on the sawdust blower
device 8 67
Switching On and Off 9 68
Guide the power tool toward the
workpiece only when switched on 10 68
Plunge Cutting 11 69
Lubrication when cutting metal 12 69
Selecting Accessories – 71 – 72
OBJ_BUCH-1524-003.book Page 11 Friday, May 31, 2013 2:03 PM
