English–1
2 609 932 218 • (02.04) T
Please observe the order number of your machine. The trade names of the individual machines may vary.
Measured values determined according to EN 50 144.
The A-weighted sound pressure level of the product is
typically:
The noise level when working can exceed 85 dB(A).
Wear ear protection!
PST 430 E/6500 E/600 PE/6500 PE/6800 PE:
The typical weighted acceleration is 5 m/s
2
.
PST 7500 PE:
The typical hand-arm vibration is below 2.5 m/s
2
.
The machine is intended for making separating cuts
and cutouts in wood, plastic, metal, ceramic plates
and rubber while resting firmly on the workpiece. It is
suitable for straight and curved cuts with bevel angles
to 45°. The saw blade recommendations are to be ob-
served.
1
On-Off switch
2
Stroke rate selection thumbwheel
3
Locking button for On-Off switch
4
Vacuum hose*
5
Base plate
6
Lever for pendulum stroke adjustment
(not for PST 430 E/6500 E)
7
Switch for sawdust blowing device (PST 7500 PE)
8
SDS lever for saw blade release
9
Guide roller
10
Saw blade*
11
Contact protector
12
Dust cover for vacuuming
13
Splintering protector*
14
Stroke rod
15
Cutting angle scale
16
Screw
17
Protractor**
18
Threaded hole
19
Front cut-out
20
Retainer
21
Parallel Guide/Circle Cutter*
* Optional accessories
** Commercially available (not included in the delivered
items)
Not all the accessories illustrated or described are in-
cluded in standard delivery.
Product Specifications
Jigsaw PST ... 430 E 6500 E 600 PE 6500 PE 6800 PE 7500 PE
Order number 0 603 ...
... 380 6.. ... 380 6../
... 380 7..
... 381 7../
... 998 6..
... 381 7.. ... 381 7.. ... 382 7..
Rated power [W] 430 450 450 450 470 600
Output power [W] 270 270 270 270 280 360
Stroke rate at no load
[min
-
1
]
500–3100 500–3100 500–3100 500–3100 500–3100 500–3100
Stroke [mm] 22 22 23 23 23 23
Stroke rate selection
●●●●●●
Pendelum action
– –
●
● ● ●
Maximum cutting depth
in wood
in aluminium
in non-alloyed steel
[mm]
[mm]
[mm]
65
15
4
65
15
4
65
15
4
65
15
4
68
15
4
75
18
6
Bevel cuts (left/right) [°] 0–45 0–45 0–45 0–45 0–45 0–45
Weight
(without accessories) approx. [kg] 1.7 1.7 1.9 1.9 1.9 2.4
Protection class /
II
/
II
/
II
/
II
/
II
/
II
Noise/Vibration Information
PST 430 E/6500 E/600 PE/
PST 6500 PE/6800 PE: 82 dB(A)
PST 7500 PE: 84 dB(A)
Intended Use
Product Elements
