Safety en
3
dition, non-metal cooking utensils and cook-
ware with non-metal handles are used, it is
safe to use this induction hob as intended.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Children must not play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of suffocation!
Children may breathe in or swallow small
parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
Keep packaging material away from chil-
dren.
Do not let children play with packaging ma-
terial.
WARNING‒Risk of poisoning!
Risk of poisoning from flue gases being
drawn back in. Room-air-dependent heat-pro-
ducing appliances (e.g. gas, oil, wood or coal-
operated heaters, continuous flow heaters or
water heaters) obtain combustion air from the
room in which they are installed and dis-
charge the exhaust gases into the open
through an exhaust gas system (e.g. a chim-
ney). With the extractor hood switched on, air
is extracted from the kitchen and the adjacent
rooms. Without an adequate supply of air, the
air pressure falls below atmospheric pressure.
Toxic gases from the flue or the extraction
shaft are sucked back into the living space.
Always ensure adequate fresh air in the
room if the appliance is being operated in
exhaust air mode at the same time as a
room-air-dependent heat-producing appli-
ance is being operated.
It is only possible to safely operate the ap-
pliance if the pressure in the room in which
the heating appliance is installed does not
drop more than 4Pa(0.04mbar) below at-
mospheric pressure. This can be achieved
whenever the air needed for combustion is
able to enter through openings that cannot
be sealed, for example in doors, windows,
incoming/exhaust air wall boxes or by
other technical means. An incoming/ex-
haust air wall box alone does not ensure
compliance with the limit.
In any case, consult your responsible chim-
ney sweep. They are able to assess the
house's entire ventilation setup and will
suggest the suitable ventilation measures
to you.
Unrestricted operation is possible if the ap-
pliance is operated exclusively in circulat-
ing-air mode.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Bosch PVQ731F15E and is the answer not in the manual?

Bosch PVQ731F15E Specifications

General IconGeneral
Built-in hoodYes
Type of extractionRecirculating
Fan noise level (max)74 dB
Fan noise level (min)69 dB
Maximum extraction power622 m³/h
Hob typeZone induction hob
Product colorBlack
Hob width size70 cm
Top surface typeCeramic
Appliance placementBuilt-in
Cooking zone 1 boost3700 W
Cooking zone 1 power2200 W
Cooking zone 1 positionLeft front
Cooking zone 2 positionLeft rear
Cooking zone 3 positionRight rear
Cooking zone 4 positionRight front
Number of cooking zones4 zone(s)
Cooking zone 1 power sourceGas
Cooking zone 2 power sourceElectric
Cooking zone 2 size (W x D)190 x 210 mm
Number of gas cooking zones0 zone(s)
Timer typeDigital
Control typeTouch
Built-in display-
Control positionFront / Top front
AC input voltage220-240 V
AC input frequency50-60 Hz
Connected load (gas)- W
Connected load (electric)7400 W
Package depth660 mm
Package width940 mm
Package height430 mm
Package weight30000 g
Keep warm functionNo
Number of boosters9
Number of power levels17
Weight and Dimensions IconWeight and Dimensions
Depth522 mm
Width710 mm
Height223 mm
Weight25200 g
Cord length1.1 m
Installation compartment width560 mm
Installation compartment depth (min)490 mm
