Stop and remove plug from the power
supply.
Place the handle in the vertical position.Turn the
machine on its right side and inspect the cutter:
If blunt or damaged, fit a new cutter as follows:
To remove the worn cutter
12
push along its
length, in direction of the arrow, as in figure
G
until it snaps off the pivot
14
.
Clean the pivot
14
of any residual plastic/debris
with a sharp knife.
To refit the new cutter
12
place the eyelet over
the pivot
14
and pull outwards until it snaps into
place.
Replace blades Easi-lite 28 (white) F016 800 009
Replace blades Easi-lite 30 (yellow)F016 S02 100
Clean the exterior of the machine thoroughly us-
ing a soft brush and cloth.
Do not use water, sol-
vents or polishes
. Remove all grass and debris,
especially from the air filter as in figure
H
.
Turn the machine on its right side and clean the
blade area. If grass cuttings are compacted in
the blade area, remove with a wooden or plas-
tic implement.
Store the machine in a dry place. Do not place
other objects on top of the machine.
To aid storage loosen the wing nuts
7
and fold
the handles. If necessary hang as shown in fig-
ure
C
.
Ensure cables are not trapped when folding/un-
folding top handles, do not drop the handles.
The following table gives checks and actions that you can perform if your machine does not operate
correctly. If these do not identify/remedy the problem contact a Atco-Qualcast Approved Service
Agent.
Warning: Switch off, remove plug from mains before investigating fault.
Blade Maintenance
Accessories
After Mowing/Storage
Fault Finding
Symptom Possible Cause Remedy
Machine fails to
operate
Power turned off.
Mains socket faulty.
Extension cable damaged.
Fuse faulty/blown.
Mower in long grass
Turn power on.
Use another socket.
Inspect cable, replace if dam-
aged.
Replace fuse.
Increase height of cut and tilt
mower.
Machine functions
intermittently
Extension cable damaged.
Machines internal wiring dam-
aged.
Inspect cable, replace if dam-
aged.
Contact your service agent.
Machine leaves
ragged finish or
motor labours
Height of cut too low.
Cutter blunt.
Underside of machine badly
clogged.
Increase height of cut
(see “Height of Cut Adjustment”).
Replace cutter
(see “Blade Maintenance”).
Clean machine
(see “After Mowing/ Storage“).
Poor hovering Blocked air filter
Underside of machine badly
clogged
Clean air filter
(see “After Mowing/ Storage”)
Clean machine
(see “After Mowing/Storage”)
Machine vibrates Fan not locked in place
Cutter stick worn or damaged
Lock cutting disc
Replace cutting stick
Easi-lite 28 Seite 6 Montag, 23. Februar 2004 2:29 14
