VI.
VI.
Component Access/Replacement
Component Access/Replacement
Water Valves (1)
Water Valves (1)
The water valve is accessed from
the front of the dishwasher base
by removing the toe kick.
To remove water valve:
Remove two (2) T-20 Torx screws from toe kick and tilt toe
kick out from under dishwasher.
Remove base insulation (on models with insulation).
Move sump inlet hose away from water valve (without
disconnecting it).
Disconnect wires from water valve, including ground wire.
Remove two (2) T-20 Torx screws from water valve.
Pull valve out from dishwasher and disconnect water hose
from rear of valve. Remove any water from sump & base.
Removing toe kick
Moving sump hose
Removing hose clamp
