Toe Panel Kits
(Model Dependent; your dishwasher is supplied with one of the toe panel
kits shown below)
Slotted Toe Panel
2 - Screws Ø 4x16 mm
Non-Slotted Toe Panel
2- Screws Ø 4.2x12.7 mm
Toe Panel Mounting Brackets (used with non-
slotted toe panel shown above)
G
H
I
J
K
L
Plastic Toe Panel
M
Slotted Toe Panel (used with Plastic Toe Panel)
H
4 - Screws Ø 4x16 mm
2 - Screws Ø 4x16 mm
H
