1 695 105 431 2010-02-16| Robert Bosch GmbH
24 | TCE 4225 | User informationen
2. User information
2.1 Important notes
Important information on copyright, liability and warran-
ty provisions, as well as on equipment users and com-
pany obligations, can be found in the separate manual
"Important notes on and safety instructions for Bosch
Tire Equipment". These instructions must be carefully
studied prior to start-up, connection and operation of
the TCE 4225 and must always be heeded.
2.2 Safety instructions
All the pertinent safety instructions can be found in the
separate manual "Important notes on and safety instruc-
tions for Bosch Tire Equipment". These instructions must
be carefully studied prior to start-up, connection and
operation of the TCE 4225 and must always be heeded.
2.3 Electromagnetic compatibility (EMC)
The TCE 4225 is a class A product as per EN 61 326.
3. Product description
3.1 Expected use
TCE 4225 is a modern tire-changer for use on cars. With
the aid of relevant accessories, it can also be used on
motorcycles.
i TCE 4225 has to be used exclusively for the specified
purpose and only in the functioning scope shown in
these instructions. Any other use different from that
specified has to be considered improper and there-
fore not allowed.
i The manufacturer is not liable for any damage
caused by improper use.
3.2 Requirements
TCE 4225 has to be installed on an even surface made
of concrete or similar materials, and has to be firmly
anchored. A pneumatic connection is requested.
3.3 Delivery specification
Denomination Order code
TCE 4225
Bead lifting lever 1 695 102 683
Brush 1 695 100 123
Inflation manometer 1 695 103 996
Protection tab 1 695 101 608
Mounting tool cover 1 695 102 725
Bulb container 1 695 103 968
Bulb container support 1 695 104 083
3.4 Special accessories
Denomination Order code
Bead locking clamp 1 695 103 302
Upper wedge 1 695 103 216
Motor adaptors for 20" plate 1 695 105 438
Scooter adaptors for 20" plate 1 695 105 440
Roller 1 695 900 005
Object holder 1 695 900 003
Bead pressing device 1 695 103 261
20" motor bead breaker support 1 695 103 252
Motor tool kit 1 695 103 210
Bead breaker blade protection 1 695 102 090
Aisles protections for 20" plate 1 695 105 083
Tool tab protections (5 pieces) 1 695 101 608
TCE 200 1 695 900 002
Wheel hoisting device 1 695 900 025
