For technicians only
Technical data
Model TR5500T 80.. TR5500T 100.. TR5500T 120.. TR5500T 150..
Volume Litres 80,0 100,0 120,0 150,0
Weight when full kg 106 133 162 197
Maximum operating
pressure
Mpa
(bar)
0,6 (6)
Heating time in hrs,
with cold water intake
of ca. 15°C, to a temperature
of 85°C
1kW 6,8 8,5 10,3 12,8
2kW 3,4 4,3 5,1 6,4
3kW 2,3 2,8 3,4 4,3
4kW 1,7 2,1 2,6 3,2
6kW 1,1 1,4 1,7 2,01
Water connection G 1/2 male thread
Model TR5500T 80.. TR5500T 100.. TR5500T 120.. TR5500T 150..
Energy class C C C C
Load profile MLL L
Power consumption yearly in kWh (kWh) 1378 2712 2709 2711
Power consumption daily in kWh (kWh) 6,405 12,557 12,541 12,553
Sound power level in dB (dB) 15 15 15 15
Warm water effiency in % % 37,3 37,8 37,8 37,8
Mixing water 40 °C
(Tset 60 °C)
(l) 95 145 170 215
Application range within
water types
Water hardness °dH ≥ 6
Electrical
conductivity
[μS/cm] ≥ 100
Model TR5500T 80.. TR5500T 100.. TR5500T 120.. TR5500T 150..
Double-power operation 1/N/PE~230V
1-4 kW 1/N/PE~230 V min 10 A // max 20 A
2-4 kW 1/N/PE~230 V min 10 A // max 20 A
3-4 kW 1/N/PE~230 V min 16 A // max 20 A
Current limits 2/N/PE~230V
1 - 4 kW 2/N/PE~230 V min 10 A // max 20 A
2- 4 kW 2/N/PE~230 V min 10 A // max 20 A
3- 4 kW 2/N/PE~230 V min 16 A // max 20 A
Secure base load (min. xx A) 2/N/PE~230V
1 - 6 kW 2/N/PE~230 V min 10 A // max 20 A
2- 6 kW 2/N/PE~230 V min 10 A // max 20 A
3- 6 kW 2/N/PE~230 V min 16 A // max 20 A
Secure max. load (max. xx A) 3/N/PE~230V
1 - 6 kW 3/N/PE~230 V min 10 A // max 20 A
2- 6 kW 3/N/PE~230 V min 10 A // max 20 A
3- 6 kW 3/N/PE~230 V min 16 A // max 20 A
Model TR5500T 80.. - TR5500T 150..
1/N/PE~230V 1kW 1 kW 1/N/PE~230 V // 1 x min 10 A
Single-power operation 1/N/PE~230V 2kW 2 kW 1/N/PE~230 V // 1 x min 10 A
1/N/PE~230V 3kW 3 kW 1/N/PE~230 V // 1 x min 16 A
Current limits 1/N/PE~230V 4kW 4 kW 1/N/PE~230 V // 1 x min 20 A
2/N/PE~230V 3kW 3 kW 2/N/PE~230 V // 2 x min 16 A
Secure load
2/N/PE~230V 4kW 4 kW 2/N/PE~230 V // 2 x min 10 A
3/N/PE~230V 6kW 6 kW 3/N/PE~230 V // 3 x min 10 A
1/N/PE~230V 2kW 2 kW 1/N/PE~230 V // 1 x min 10 A
Boiler mode operation
1/N/PE~230V 3kW 3 kW 1/N/PE~230 V // 1 x min 16 A
1/N/PE~230V 4kW 4 kW 1/N/PE~230 V // 1 x min 20 A
Current limits
2/N/PE~230V 2kW 2 kW 2/N/PE~230 V // 2 x min 10 A
2/N/PE~230V 3kW 3 kW 2/N/PE~230 V // 2 x min 10 A
2/N/PE~230V 4kW 6 kW 2/N/PE~230 V // 2 x min 16 A
3/N/PE~230V 2kW 2 kW 3/N/PE~230 V // 3 x min 10 A
Secure load
3/N/PE~230V 3kW 3 kW 3/N/PE~230 V // 3 x min 10 A
3/N/PE~230V 6kW 6 kW 3/N/PE~230 V // 3 x min 10 A
