ELECTRICAL PART LIST
1401 Series II and 1201
Resistors
Reference Designator Description Part Number Note
R11, 12, 21, 22, 31, 32, 41,
42
.47 Ohm, 5%, CF 108904
R13, 14, 23, 24, 33, 34, 43,
44, 125, 126, 225, 226
27 Ohm, 5%, CF 117704-1212705 4
R15, 25, 35, 45, 129, 229 220 Ohm, %5, CF 117704-1212215 4
R16, 26, 36, 46, 130, 230 47 Ohm, 5%, CF 117704-1214705 4
R17, 37 11K, 1%, MF 119976-2211102
R18, 28, 38, 48, 121, 141,
221
910 Ohm, 5%, CF 117704-1219115 4
R27, 47, 103, 222 17.8K, Ohm, 1%, MF 119976-2211782 4
R51, 71, 103, 203 20 Ohm, 1W, 5% 104064-200 4
R52, 53, 72, 73, 101, 102,
112, 113, 115, 201, 202,
516, 517
100K, 1%, MF 119976-2221003 4
R54, 55, 66, 74, 75, 86,
104, 105, 115, 204, 205,
215, 513
10K, 1%, MF, 1/4W 119976-2211002 4
R56, 57, 76, 77 51.1K, 1%, MF 119976-2225112
R58 12.1K, 1%, MF 119976-2221212
R59, 64, 79, 84 4.75 Ohm, 1%, MF 119976-2224751
R60, 80, 105, 107 5.62K, 1%, MF 119976-2215621
R61, 81 200K, 1%, MF 119976-2212003
R63 15K, 1%, MF 119976-2221502
R65, 85 8.25K, 1%, MF 119976-2218251
R67, 87 3.32K, 1%, MF 119976-2213321
R68, 88, 117, 217, 305 2.00K, 1%, MF 119976-2212001 4
R69 1.30K, 1%, MF 119976-2211301
R78, 110, 210, 514 12.1K, 1%, MF 119976-2211212 4
R82, 110 1K, 5%, CF 117704-1211025
R83, 112, 212, 119, 122 15K, 1%, MF 119976-2211502 4
R86 10K, 1%, MF, 1/4W 119976-2221002
R88 2K, 1%, MF 119976-2222001
R89 1.3K, 1%, MF 119976-2221301
R90, 116, 216 39.2K, 1%, MF 119976-2213922 4
R91 39.2K, 1%, MF 119976-2223922
R92 61.9K, 1%, MF 119976-2226192
R93 150K, 1%, MF 119976-2221503
R94, 97, 150 6.81K, 1%, MF 119976-2216811
R95, 96 6.81 Ohm, 1%, MF 119976-2226811
R101, 102, 104 17.8K, 1%, MF 119976-2221782
R106 3.01K, 1%, MF 119976-2213011
R106, 107, 206, 207 25.5K, 1%, MF, 1/4W 119976-2212552 4
R108 3.01K, 1%, MF 119976-2223011
R108, 208 24.9K, 1%, MF, 1/4W 119976-2212492 4
R109 75.5K, 1%, MF, 1/4W 119976-2217502 4
R111 10 Ohm, 5%, CF 117704-1211005
R111, 211 4.75K, 1%, MF, 1/4W 119976-2214751 4
R113 100K, 1%, MF 119976-2211003
R113, 213 8.25K, 1%, MF, 1/4W 119976-2218251 4
R114 33.2K, 1%, MF 119976-2223322
R114, 214 4.32K, 1%, MF, 1/4W 119976-2214321 4
