ELECTRICAL PART LIST
1401 Series II and 1201
Resistors (continued)
Reference Designator Description Part Number Note
R116, 121-123, 503, 504,
601
47K, 5%, CF 117704-1214735 4
R117, 126-128, 301, 303,
401, 403, 507, 510, 604,
605
10K, 5%, CF 117704-1211035 4
R118 360 Ohm, 5%, CF 117704-1223615
R118 2.32K, 1%, MF, 1/4W 119976-2212321 4
R119 560 Ohm, 5%, CF 117704-1225615 4
R120 1.8K, 5%, CF 117704-1221825
R120, 220 6.19K, 1%, MF, 1/4W 119976-2216191 4
R123, 124, 223, 224, 522 4.7K, 5%, CF, 1/4W 117704-1214725 4
R124 220K, 5%, CF 117704-1212245
R125 18 Ohm, 5%, CF 117704-1211805
R127, 128, 227, 228 .47 Ohm, 5%, 2W 123355 4
R129-136 4.7K, 5%, CF 117704-1214725
R131, 231 7.15K, 1%, MF, 1/4W 119976-2217151 4
R137, 139 .03 Ohm, 2W, 10% 119748
R142 2.2 Ohm, .5W, 1%, MF 113777-2R2
R145, 146, 512 560 Ohm, 5%, CF 117704-1215615 4
R209 75.0K, 1%, MF, 1/4W 119976-2227502 4
R218 4.99K, 1%, MF, 1/4W 119976-2214991 4
R219, 519 18.2K, 1%, MF, 1/4W 119976-2211822 4
R302, 402 2.7K, 5%, CF, 1/4W 117704-1212725 4
R304, 404 51K, 5%, CF, 1/4W 117704-1215135 4
R405 1.82K, 1%, MF, 1/4W 119976-2211821 4
R501 61.9K, 1%, MF, 1/4W 119976-2216192 4
R502 150K, 1%, MF, 1/4W 119976-2211503 4
R505 10 Ohm, 5%, CF, 1/4W 117704-1211005 4
R506, 508, 509 15K, 5%, CF, 1/4W 117704-1211535 4
R511 .03 Ohm, 10%, 2W 119748 4
R515 29.4K, 1%, MF, 1/4W 119976-2212942 4
R518 332, Ohm, 1%, MF, 1/4W 119976-2213320 4
R520 1.2K, 5%, CF, 1/4W 117704-1211225 4
R521 470 Ohm, 5%, CF, 1/4W 117704-1214715 4
R602 5.1K, 5%, CF, 1/4W 117704-1215125 4
R603 91K, 5%, CF, 1/4W 117704-1219135 4
