Bose 301 Series Service Manual

4
4.6 Remount the tweeter using the #8-32 screw.
4.7 Remount the woofer using the four #8-11
screws.
5. Remounting the Grilles: Both side and front
grilles can only be mounted one way.
5.1 Side Grille: Align the feet with the fast-on
grommets. Press in lightly until the grille feet
are fully inserted into the grommets and the
snap is engaged.
5.2 Front Grille: Align the feet with the four mount-
ing holes on the end caps and press the grille in
lightly until the snaps are engaged.
