Bose 402 Series User Manual

2
SPECIFICATIONS
WARRANTY
5 year limited warranty
PROPRIETARY INFORMATION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION
OF BOSE
®
CORPORATION WHICH IS BEING FURNISHED
ONLY FOR THE PURPOSE OF SERVICING THE IDENTIFIED
BOSE PRODUCT BY AN AUTHORIZED BOSE SERVICE CEN-
TER OR OWNER OF THE BOSE PRODUCT, AND SHALL NOT
BE REPRODUCED OR USED FOR ANY OTHER PURPOSE.
Specifications ....................................................................................................................................1
Disassembly/Assembly Procedures ........................................................................................... 2-3
Figure 1. Schematic Diagram ..............................................................................................................3
Test Procedures ................................................................................................................................4
Main Part List.....................................................................................................................................5
Figure 2. Exploded View ......................................................................................................................5
Crossover PCB Part List ..................................................................................................................6
Figure 3. Crossover PCB Layout ........................................................................................................6
Packaging Part List ...........................................................................................................................6
Figure 4. Packaging View ....................................................................................................................6
External dimensions:
Single speaker: 23.3" H x 8.2" W x 7.8" D (59.2 x 20.8 x 19.8)cm
Packed system: 27.0" H x 12.0" W x 11.0" D (68.6 x 30.5 x 27.9)cm
Weight:
Single speaker: 17.5 lbs (7.94 kg)
Packed system: 21.3 lbs (9.66 kg)
Transducer:
Four 4.5" environmental drivers per enclosure
Internal cabinet volume:
1067.9 cu. In. (17.5 liters)
Port:
Type: Two rectangular ports located at the top and bottom.
Total port area: 8.84 sq. in. (57 sq. cm)
Port length: 3.23" (8.2cm)
Resonance frequency: 90 Hz
Impedance:
8 ± 2 Ohm
Power handling:
120W continuous per IEC-268-5
Sensitivity:
90 dB SPL, 1W, 1m
CONTENTS
