66
REFERENCE
ItalianoSvenska DeutschNederlands EnglishFrançais Español
7. Insert the TV sensor plug into the TV Sensor
connector on the media center.
8. Locate the Audio IN connectors that are labeled TV
on the back of the media center.
9. Insert the red and white audio plugs on the SCART
adapter into these connectors.
Be sure to match the colors on the plugs to the
connector colors: red to red and white to white.
Note: When this SCART connection to the TV is
completed, see on “Connecting another device
(cable or satellite box, VCR, or DVR)” on page 29 to
continue with connections.
(cont.) For TVs requiring SCART (in Europe, only)
10.LIV_Reference.fm Page 66 Thursday, January 15, 2009 3:56 PM
