8 • English DesignMax DM5SE • Installation Guide

BoseProfessional.com

Installation

Removing the Grille

There are two small openings on either side of the grille (1). Along the side

of the loudspeaker with the bracket slots, insert a small, ﬂat tool into the

grille openings to disengage the release tabs. Pull the grille away from the

loudspeaker.

q q

Safety and Regulatory Compliance

The DesignMax DM5SE loudspeaker has passed testing and complies with the following speciﬁcations and uses:

Listed to ANSI/UL 1480A-2016, Speakers for Commercial & Safety Professional Use

General-Purpose Use - UL Category UEAY, File Number S 5591 Control Number 3N89

The DesignMax DM5SE is suitable for use outdoors in wet locations

Suitable for installation using Class 1, Class 2, Class 3 wiring methods in accordance with NFPA 70, National Electrical Code,

2017, Article 640

The DesignMax DM5SE loudspeaker has been designed to the requirements deﬁned in the following European regulatory speciﬁcation

for combination systems:

Tested to IEC60268-5, 2007

Adjusting the Logo

You can rotate the Bose logo to align with your loudspeaker

orientation. With one hand, press the button on the back of

the grille. Rotate the logo with the other hand. The logo can be

rotated clockwise or counterclockwise.

Note: Do not pinch the button inward unless you intend to

remove the logo.

Attaching the Grille

Place the grille over the front of the loudspeaker and push it

ﬁrmly until it snaps into place.
