Bose FreeSpace DS 40SE

14
MAIN PART LIST
FreeSpace
®
DS 40SE Loudspeaker, Ceiling-Mount Version (see Figure 6)
Item
Number
Description Bose
©
Part
Number
Vendor Part Number Qty. Note
1 SCREW, B-TITE, PAN, M4X8 - 2950-4008+H000 4 4
2 LOGO ASSY, BLACK
LOGO ASSY, WHITE
303038-001
303038-002
SVC-SLAR11+LOGO
SVC-SLAR12+LOGO
1
3 ENDCAP, GRILLE, BLACK
ENDCAP, GRILLE, WHITE
324008-011S
324008-021S
4155-4401+2
4155-4402+2
1
4 GRILLE ASSY, INCLUDES
SCREWS, GASKET AND LOGO,
BLACK
WHITE
326912-011S
326912-021S
SVC-SLAR11+GRIL
SVC-SLAR12+GRIL
1
5 KNOB, SWITCH, D30 295898-004 2447-3605+1 1
6 SPRING, LOGO, D8X8 - 2510-3941+0 1 4
7 WASHER, M6.2X1.2X12 - 2600-6212+1207 1 4
8 WOOFER, 4.5 INCH, 8 OHM 324015-001S 1527-0001+0 1
9 FOAM, D12, L=18 - 4149-1171+0 2 4
10 FRONT BAFFLE, BLACK - 4155-4391+4 1 4
11 GASKET, PE, 600X10X1.0MM - 4149-7221+0 3.5 4
12 SWITCH, ROTARY, 1P6T - 5200-4933+1 1 4
13 SURFACE PORT, PP+10% GF - 4155-4381+0 1 4
14 SCREW, B-TITE, BIND, M4X16 - 2954-4016+H000 2 4
15 ENCLOSURE, REAR, PC/ABS,
BLACK
WHITE
-
-
4155-4373+3
4155-4374+3
1 4
16 SCREW, B-TITE, BIND, M4X16 - 2954-4016+H000 4 4
17 TRANSFORMER ASSY
W/ SWITCH (includes item 12)
326913-001S SVC-SLAR11+TRAN 1
18
BRACKET ARM, CEILING MNT
(includes hardware)
BLACK
WHITE
716377-0110
716377-0210
472651-1
472651-2
1
19 SCREW, MOUNT, M4x18.5 - - 4 4
20 CABLE W/CONNECTOR
BLACK
WHITE
-
-
7012-7710+0
7012-7711+0
1 4
21 SCREW, B-TITE, BIND, M4X16 - 2954-4016+H000 6 4
22 SCREW, B-TITE, BIND, M4X16 - 2954-4016+H000 4 4
23 EVA GASKET - 4149-1781+0 1 4
24 ACOUST FUZZ, 120x200x25MM - 4149-7321+1 2 4
25 WASHER, METAL, M4x0.8x10 - 2600-4008+100H 2 4
26 SCREW, B-TITE, PAN, M3x8 - 2950-3008+H010 1 4
27 SCREW, B-TITE, PAN, M4x12 - 2950-4012+H000 4 4
28 PCB ASSY, LOAD COM 324014-001S PCB-FLAR11+LOAD 1
29 WASHER, 4.25x7.5x0.75 - 4166-0012+1 4 4
- PCB ASSY, PROTECTION 324014-001S SVC-SLAR11+PCB 1
