MAIN ASSEMBLY LIST
Item
Number
Description Part Number Qty Notes
1 PCBA 740558-0010 1
1,3
2 DRIVERS 715491-0010 2
3
3 ENCLOSURE SUB ASSY 740777-001S 1
3
4 METAL GRILLE 740551-0010 1
5 PCBA COVER 740440-0010 1
3
6 PCBA COVER SCREWS 740664-0010 5
7 GRILLE SCREWS 740663-0010 2
8 TRANSDUCER SCREWS 740661-0010 8
9 CABLE, FIBER OPTICAL, 3.5mm 629769-0010 1
10 CABLE, DIGITAL COAX 342771-1010 1
11 POWER SUPPLY , FLOOR WART, 20V, 1.8A 748806-0010 2 3
12 RUBBER FOOT 740557-0010 2
3
Solo 5 Main Assembly List (see Figure 2)
