20
ELECTRICAL PART LIST
T4S Main PCB Assembly
Integrated Circuits (continued)
Reference Designator Description Vendor Part
Number
Note
U7 REG, CJ7915, TO-252-2, JCET T610600099768
U8 IC, DRIVER, TPS61169DCKR,
SOT(5), TI
T610900023502
U9 IC, SP, ADUM4160BRWZ, SOIC-16,
ADI
T610000059036
VR1, VR2, VR3, VR4 VR, CA, 10K, C, 20X9.8MM,
RV09ACF-40-20F-10C10K-0068
T531230000119
VR17 VR, CA, 10K, B, 15.4X14X26,
XV014112YGPV26.4FR1B10K
T531220000216
VR9, VR10, VR11, VR12, VR18 VR, CA, 10K, B, 15.4X14X24,
XV014112YGPV24FR1B10K
T531220000116
Miscellaneous
Reference Designator Description Vendor Part
Number
Note
F1, F2 FUSE, 30V, 200MA, 1206, 0ZCJ0,
0ZCJ0020FF2E
T690100003000 3
J1, J2, J3, J4, J7, J8 6.35MM STEREO JACK, NRJ6HF T710200009700
J10 USB, TYPE B319BF-K-C2-M-BN, 4P T710200009500
J11 6.35MM STEREO JACK WITH HALF
THREADED, NMJ6HHD2
T710200009800
J12 CONN, CF2014, .5MM, HLD 1,
CF20141V0R0-NH
T690300062300
J14 HEADER, SMT, 2*5PIN, 1.27-2X5SW-
5.5B, 90
T690300079300
J15 HEAD, DUAL PIN, 14P, P2.54, 180,
GOLD, CCP254010-0714
T690300022200
J9 USB, SOCKET TYPE A, USB-A-
M6+4P-5W-O, 4PI
T710200009400
P1, P3 24P, P=2.0MM, 180, CH74242M100-
0P
T690300104100
P2 GP, CONNECTOR, B4B-XH-A, 4-PIN,
L, CCN250000-0104
T690300029000
SW1 PUSHBUTTON SWITCH, PB-22E80-
S-E
T670100001700
SW2, SW3, SW4 ENCODER, RE12CF-41-20F-24P,
180ｰK
T670500001900
SW5 ENCODER, SDB161EPVB16.7FR-1-
4-12-12PC
T670500002000
T1 TRANSFORMER, 6.6V, 3.3V, 4PI,
MURATA, 78604\9C
T622000010300
T2, T3 TRANSFORMER, 3.3V, 3.3V, 4PI,
MURATA, DA101C
T622000008300
Y1 CRYSTAL, 12MHZ, 20, SMD, TXC,
7M1200, K7M12000039
T690900008100
Y2 CRYSTAL, 12.288MHZ,
SMD, SIWARD, XTL571, K,
XTL571200-M13-105, SX-322
T690900008000
Y3 OSC, 11.28960 MHZ, SMD, TXC,
7X1120, K7X11200002
T690900008400
To Next Page
