7
P
ACKAGING P
ART LIST
T4S T
oneMatch
Audio Engine (see Figure 1)
Figure 1. T4S Packing View
1
2
3
4
5
6
Item Number
Description
Part Number
Note
1
CART
ON, T4S, SVCE
802932-001S
2
GUIDE, OWNERS, T4S/T8S
801230-0010
3
ETHERCON INTERCONNECTION CABLE (TO POWER ST
AND)
042536
4
FOAM, EPE, LEFT
,
T4S, SVCE
804152-001S
5
FOAM, EPE, RIGHT
,
T4S, SVCE
804153-001S
6
POL
Y BAG, EPE,
T4S, SVCE
804151-001S
6
8
