Image Setting
• To remove the on-screen parking guidelines, cut open the white wire
loop which splits from the camera’s cable. Otherwise, keep the white
wire loop uncut.
• If the camera image appears reverse, cut open the blue wire loop
which splits from the camera’s cable. Otherwise, keep the blue wire
loop uncut.
• Make sure to unplug the power cable from the camera and plug it again
to enable the new setting (after cutting off the white or blue wire loop).
Specications
Power supply ................................... 12 VDC
Viewing angle ..................................170°
TV system ........................................NTSC
Video output ....................................1.0 vp-p, 75 Ω
S/N ratio ...........................................≤45 dB
Ingress protection rating .................. IP67 (waterproof)
Operating conditions ........................ -22 to +140°F (-30 to +60°C)
max. 95% RH
White balance ..................................Auto
Illumination ......................................min. 0.1 lux
Automatic gain control (AGC) .......... Auto
Resolution (TV lines) .......................480
Electronic shutter speed .................. 1/60 (NTSC)
Effective pixels .................................648 x 488
Dimensions (L x W x H) ................... 7.756” x 0.88” x 0.88”
197 x 22 x 22 mm
Cable length .................................... 197”/5m (video cable); 39”/1m (power
cable); 20”/0.5m (camera’s cable)
Specications are subject to change without notice.
