1.6LocationsandNamesofControlsonorintheunit
1.OPENbutton
2.POWER/MUTEbutton
3.Monitor
4.AVINsocket
5.DiscSlot
6.USBJack
7.SD/MMCCardSlot
8.MODEbutton
9.VOLknob
10.>>|button
11.|<<button
12.PLAY/PAUSE/1button
13.INT/2button
14.RPT/3button
15.RDM/4button
16.-10/5button
17.+10/6button
18.BANDbutton
19.APSbutton
20.EJECTbutton
21.RESETbutton
22.SmallLCDScreen
23.IRRemoteSensor
24.RELbutton
TheFrontFacetafterremovingthefrontpanel
1
2
3
4
6
10
9
8
11
12
14
16
17
5
13
18
15
19
20
2223
24
FrontPanel
7 21
25
SD/MMC
BV9982I
