7
STEP 4 - LIFT THE main BODY ONTO THE frame
Lock the wheels on the two locking Castors (2) to ensure the BBQ
cannot move.
To make lifting easier, before placing the Main Body (8) on to the
frame remove all the accessories from within it.
Place one of your hands in the bottom vent of the ceramic body and
the other under the main body while lifting.
CAUTION:
Use a minimum of two people when lifting the Main Body onto the
frame. Lifting by the hinge or the side tables could result in injury
and/or damage to the product. Place the Main Body on the cart with
the bottom vent facing to the front allowing the vent to open and
close without any obstruction.
STEP 5 - ATTACH THE TOP vent
Once the Main Body is securely seated in the frame,
attach the Top Vent (9). Align the side notch with the
thermometer at the front, and set over the top
opening. Secure using the pre-attached nut and bolt.
STEP 6 - INSTALL THE SIDE SHELF
BRACKETS
Attach the four Side Shelf Brackets (12) to the
Main Body (8) using the 16 pre-attached bolts
with their corresponding washers, locking
washers, and nuts.
When fitting the brackets, loosely fit all 4 bolts to
each bracket before fully tightening.
