Electrical requirements 115V, 60Hz
Power output 1500W
Rated current 13.5A
Motor speed 3400 RPM
Power cable SJTW 14 AWG (2.08mm²)
Max splitting force* 7 ton
Max splitting length 20.5 in
Max splitting diameter 10 in
Hydraulic pressure 3500 PSI
Cylinder bore 2.2 in
Cycle time*
Feed 9 sec
Retract 5 sec
Max cylinder stroke 17 in
Oil capacity 3.8 L
Machine dimensions (L×W×H) (in) 39.5x13.5x20
Machine net weight 117 lbs
*Tonnage and cycle times may vary dependent upon electricity supply, mechanical and
environmental conditions.
