Boss MGV520B - Wire Diagram

Black
Bullet Socket
Reverse Input
Fuse 15A
USB Socket
Ant Socket
Violet/White
Main Output Wire
1
2
3
4
5
6
7
8
9
10
11
12
Bullet Socket Function
No Colour Function No Colour Function
Red
White/B
White
Yellow
Grey/B
Grey
Acc
FL-
FL+
Constant
FR-
FR+
Blue
Green/B
Green
Black
Purple/B
Purple
Remote
RL-
RL+
Gnd
RR-
RR+
White
L Output
Red
R Output
Yellow
Video Input
White
L Input
Red
R Input
White
Sub Output
Red
Sub Output
White
L Output
Red
R Output
Orange
Rear Camera
Input
Illumination Input
Orange
Rear Camera Output
Red/White
Aux Power Output
Red/Violet
Brown
Yellow
Green
White
Black
Audio input
Video In
Sub Output
Rear Output
Front Output
