Boss TPSE201 - Page 15

15
The following is an example list of CH programmed operations.
Program Output
CH
Day of week
1
On 06:00
Off 08:00
2
On 10:00
Off 12:00
3
On 18:00
Off 22:00
1) In Auto mode
Case 1: Device is in channel ON state.
- At 11:00. Device is in Program 2 On and the channel is ON.
- The user presses Adv. The relay switches OFF and ADV icon is shown.
- At 12:00, device reaches the time of Program 2 Off. The channel is kept OFF but ADV icon is
NOT shown. i.e. Advance override is finished.
- (Similar when Device in Program 1 Off state)
Case 2: Device is in channel OFF state
- At 9:00 device is in Program 1 Off state and the channel is OFF.
- The user presses Adv. The relay switches ON and ADV icon is shown.
- @10:00, device reaches start time of Program2-On. Now the relay is kept On but ADV icon is
NOT shown. i.e. Advance override is finished.
2) In Once mode
Case 1: Device is in channel ON state.
- At 11:00, device is in Program 2 On and the channel is ON.
- The user presses Adv. The relay switches OFF and the ADV icon is shown.
- At 22:00, the relay is kept OFF but the ADV icon is NOT shown. i.e. Advance override is
finished.
- At 06:00 of the next day, the device reaches the start time of program 1 On and the channel
switches On.
Case 2: Device is in channel OFF state
- At 09:00, device is in Program 1 Off state but the channel is ON while in Once mode
- The user presses the Adv, the channel switches OFF and the ADV icon is shown.
- At 22:00, the channel is kept OFF but the ADV icon is NOT shown. i.e. Advance override is
finished.
- At 06:00 of the next day, the device reaches the start time of program 1 On and the channel
switches On.
