4
Connecting Your VRS Micro Speakers
Connect the speaker’s terminals to those on the amplifier or receiver designated for “surround” or
“rear channel effects.” Maintain consistency of the + (red) and – (black) connections by using the
markings on the wire.
We recommend 18-gauge (or heavier) speaker wire for runs up to 25' (8m), and thicker 16-gauge
speaker wire for longer runs. Strip
1
⁄2" (12mm) of insulation from the ends of each wire to expose
the conductors. Tightly twist the wire strands together. Maintain the consistency of the + (red) and
– (black) connections.
IMPORTANT: Typically, one side of the hook-up wire is ribbed and the
other is smooth. Connect the ribbed side to the + (red) terminals and
the smooth side to the – (black) terminals.
WARNING: To prevent electrical shock, always switch off the amplifier
or receiver when making connections to the speaker.
Using the five-way binding posts: The binding posts permit easy con-
nection to banana plugs, pins, spade lugs and bare wire. The metal sur-
faces are plated with 24K gold to resist corrosion.
