Battery Pack In Series And Parallel
2. When connecting in series and parallel at the same time, ① the
batteries should be connected in parallel first, and ② the battery
packs that have been connected in parallel should be connected
in series
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
12V/100Ah
3. After completing the series and parallel connection, the battery
pack system becomes 24V/ 200Ah.
Load (+)
Load (-)
① ②
