Quick Start Guide
Bowens.co.uk XMT user guide
Quick Start Guide
The following is a quickstart guide to the individual controls, display and functions.
REAR PANEL CONTROLS:
PUSH BUTTONS:
Primary (Top) Functions:
ON - Toggles power to the unit on and off.
MODE - Selects flash mode (Flash, Strobe or TTL).
TEST - Open / test flash.
SYNC - Selects sync mode (2.4Ghz radio, Optical transmission, Photocell).
GROUP - Toggles through available radio group settings (A - E).
LAMP - Toggles through available modelling lamp output settings.
Secondary (Bottom) Functions:
MENU - Selects advanced user menu system.
HSS - Selects High-Speed Sync mode.
CHANNEL - Selects radio channel settings (1 - 32).
Unless specified all buttons operate as follow:
• Single press to toggle through available options for primary (top) function.
• Press and hold to select secondary function.
ROTARY CONTROL DIAL:
Turn the Rotary Control Dial clockwise or anti-clockwise to adjust function / setting values.
Push to confirm setting / values.
FUNCTIONS OVERVIEW:
FUNCTION
POWER
MODE
TEST
SYNC
GROUP
LAMP
MENU
HSS
CHANNEL
DESCRIPTION
Power's the unit on and off.
Available flash modes include: Flash, Strobe and TTL.
Open / test flash the unit.
Available sync options include: 2.4Ghz radio, Optical transmission and
Photocell.
Available groups include: A to E.
Adjusts modelling lamp output; Off, 30% 60% or 100%.
Advanced menu functions include: Sync Delay, Photocell, Beep, Standby,
Optical, Back Light, Contrast and Reset.
High-Speed Sync up to 1/8000sec.
Available channels include: 1 to 32.
