Bowens XMTR - XMTR and Display Overview; Device Components and Display

6
XMTRS and Display
Bowens.co.uk XMTR user guide
XMTR and Display
1. Display Screen
2. Scroll Wheel
3. Channel/Set Button
4. Group Button
5. Mode Button
6. Hotshoe Mount &
Locking Thumb Screw
7. AF Grid Transmitter
8. AF Grid Transmitter
On/Off
9. Power On/Off
10. Test/Open Flash
11. Micro USB
12. PC Sync
1
3
4
5
2
10
9
8
7
6
11
12
D
A
A. Group B. Flash Power C. Flash mode
D. Channel
B
C
