Bowers & Wilkins AS1 Owner's Manual

AS1
Description
Drive unit
System frequency range
System frequency response
Amplifier
Dimensions
Internal Volume
Net Weight
Active vented-box system
1x ø165mm (6.5in) cone bass
-6dB 27Hz-100Hz Music/Movie mode
±3dB 34Hz to 75Hz on reference axis Movie mode
±3dB 31Hz to 75Hz on reference axis Music mode
Power output 85W continuous
Input impedance 100kΩ
Signal/Noise 94dB
Functions Input level control
Music/Movies switch
Inputs Line In (RCA/Phono)
Speaker level In (Spring Clips)
Outputs Line Out (RCA/Phono)
Speaker Level Out (Spring Clips unfiltered)
Height: 378mm (14.9in)
Width: 215mm (8.5in)
Depth: 385mm (15.2in)
16.5 litres (5.5 cu ft)
11kg (24.2 lb)

Bowers & Wilkins AS1 Specifications

General

Brand	Bowers & Wilkins
Model	AS1
Category	Speakers
Language	English
