6. Technical data
Dimensions and weigths Version 1 with
footrest
Version 2 with
leg rest
Total length with/without
leg rest (cm):
87 - 99,
standard: 93
90 - 102/79 - 91
standard: 96/85
Width (cm): SB+17 SB+17
Height (cm): 82-97 82-97
Folded (BxHxL) (cm): 30x82x93 30x82x93
Height of handle (cm): 80-95 80-95
Lower leg length (cm): 45 - 55,5 40 - 48
Footrest angle (°): +/- 25 +/- 10
Knee angle (°): 108 105
Unloaded weight (kg): 14,8 14,8
Max. weight capacity (kg): 135
Seat angle (°): 0 bis 17, standard: 3
Seat width (cm): 36/38/40/42/44/46/48/50/52
Seat depth (cm): 42 - 46/48 - 52, standard: 42 - 46
Front seat height (cm): 50/51/52/53/54/55/56
Rear seat height (cm): 42/44/46/48/50/52
Seat back angle (°): 75/81/87/93/99, standard: 90
Seat back height (cm): 30 - 45 mit 2,5 cm increments, stan-
dard: 30
Height of the armrests
(cm):
19 - 26,5 (optional)
Length of the armrests
(cm):
34 (optional)
Width of the armrests (cm): 5 (optional)
Driving characteristics
Version 1 with
footrest
Version 2 with leg
rest
Turning circle (mm) 600 600
Static stability (°)
Forwards: 15 15
Backwards:: 15 15
To the side: 3,8 3,8
Tyres
Drive wheels (inches): 24x1, pneumatic tyres, 750 kPa
Swivelling wheels (mm):
camber angle (°):
150 x 30, puncture resistant PU
1 - 4
Equipment
Frame: lacquered aluminium
Skirt guard:: plastic (ABS)
Seat and back pads: nylon, textile
Armrest: PU foam (optional)
