Bpt VAS/101 - Programming and Connections; Programming; Connection Examples

6
Programming
The entry panel is supplied already con gured through a call put through to any receiver that has NEVER been programmed.
It is possible, however, to add buttons or receivers as explained in the entry panel’s programming manual.
Connection examples
LITHOS
+
BOUT
-
-
-
M1
+
–
M2
M2
VAS/101
A
CL.RESM/S
M1
B
–
+
KIT FREE_LC-LVC 24810470 25-11-14_EN
