LUBRICATION
7486 1-25-06-3
GENERAL INFORMATION
 Economicalandefcientoperationofanymachineisdependentuponregularand
properlubricationofallmovingpartswithaqualitylubricant.Neglectleadstoreducedef-
ciency,heavydraft,wear,breakdown,andneedlessreplacementparts.
 Allpartsprovidedwithgreasettingsshouldbelubricatedasindicated.Ifanygrease
ttingsaremissing,replacethemimmediately.Cleanallttingsthoroughlybeforeusing
greasegun.
IMPORTANT: Avoid excessive greasing. Dirt collects on exposed grease and greatly
increases wear. After greasing, wipe off excessive grease from ttings.
LUBRICATION SYMBOLS
 Thefollowingsymbolisusedonthelubricationdiagramprintedonthefollowingpage.
Itisreproducedherewithitsmeaningforyourconvenience.
Lubricatedailyorevery8hoursofoperation,whichevercomesrst,withSAE
Multi-PurposeLubricantoranequivalentSAEMultiPurposetypegrease.
CAUTION! Shut off vehicle engine before lubricating equipment.
509&511BACKHOE
