Bradco 511 - CYLINDER AND BUCKET SPECIFICATIONS

SPECIFICATIONS
CYLINDER AND BUCKET SPECIFICATIONS
509 & 511 POWER BACKHOE
7491 10-23-12-4
CYLINDER SPECIFICATION TABLE
CYLINDER 509 511
BUCKET CYLINDER
Cylinder # ................................................... 117548 ............... 117548
Bore ...............................................................3.00" ................... 3.00"
Stroke ...........................................................18.38" ................. 18.38"
Rod Diameter ................................................2.00" ................... 2.00"
DIPPER CYLINDER
Cylinder # ....................................................86236 ................. 87029
Bore ...............................................................3.00" ................... 3.00"
Stroke ...........................................................21.38" ................. 27.00"
Rod Diameter ................................................1.75" ................... 1.75"
BOOM CYLINDER
Cylinder # ....................................................86231 ................. 82625
Bore ...............................................................2.75" ................... 3.00"
Stroke ...........................................................24.83" ................. 24.83"
Rod Diameter ................................................1.50" ................... 1.50"
SWING CYLINDER
Cylinder # ....................................................81827 ................. 81827
Bore ...............................................................2.50" ................... 2.50"
Stroke ............................................................7.65" ................... 7.65"
Rod Diameter ................................................1.25" ................... 1.25"
STABILIZER CYLINDER
Cylinder # ....................................................86605 ................. 86605
Bore ...............................................................2.50" ................... 2.50"
Stroke ...........................................................16.43" ................. 16.43"
Rod Diameter ................................................1.50" ................... 1.50"
POWER DIG BUCKETS AND CAPACITIES
Bucket Struck Heaped Weight Number
Size Cap. Ft.³ Cap. Ft.³ Lbs. Of Teeth
Standard 12" 1.43 1.83 125 3
Standard 16" 1.98 2.56 139 4
Standard 18" 2.25 2.98 147 4
Standard 20" 2.52 3.40 153 4
Standard 24" 3.07 4.32 170 5
Severe Duty 12" 1.43 1.83 140 3
Severe Duty 16" 1.98 2.56 154 4
Severe Duty 18" 2.25 2.98 162 4
Severe Duty 20" 2.52 3.40 168 4
Severe Duty 24" 3.07 4.32 185 4
